HIK DS-3E0326P-E(B) 24 Port Fast Ethernet Unmanaged POE Switch

HIK DS-3E0326P-E(B) 24 Port Fast Ethernet Unmanaged POE Switch

24 Port Fast Ethernet Unmanaged POE Switch

  • Intelligent PoE Management.  When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
  • Up to 300 m Long Range PoE Transmission.   The distance between IPCs and switch can reach maximum 300 meters.
  • 4/8-Core Adaptive Power Supply with Less Power Loss.  8-core power supply reduces the power loss on cables.
  • 6KV Surge Protection to Improve Reliability in Harsh Environment.  The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
  • Design for Video Transmission.   VIP port ensures important data transmission when network congestion occurs.

Available models:

DS-3E0326P-E(B)



Product Data

  • Network Parameters
  • Ports24 × 10/100 Mbps PoE ports, 2 × Gigabit combos
  • Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
  • Working ModeStandard mode (default); Extend mode
  • StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
  • Forwarding ModeStore-and-forward switching
  • High Priority PortsPorts 1 to 8
  • MAC Address Table4 K
  • Switching Capacity8.8 Gbps
  • Packet Forwarding Rate6.547 Mpps
  • Internal Cache2.75 Mbits
  • Ports for Long-Distance TransmissionPorts 17 to 24
  • PoE Power Supply
  • PoE StandardIEEE 802.3af, IEEE 802.3at
  • PoE Power Pin

    End-span: 1/2(-), 3/6(+)

    Mid-span: 4/5(+), 7/8(-)

    8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)

  • PoE PortPorts 1 to 24
  • Max. Port Power30 W
  • PoE Power Budget370 W
  • Dialing Function
  • Long RangePorts 17 to 24: up to 300 m; and the speed rate of the port is 10 Mbps.
  • General
  • Dimensions (W × H × D)440 mm × 44 mm × 220.8 mm
  • ShellMetal material
  • Gross Weight 3.62 kg (7.98 lb)
  • Net Weight2.75 kg (6.06 lb)
  • Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
  • Operating Humidity5% to 95% (no condensation)
  • Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
  • Storage Humidity5% to 95% (no condensation)
  • Power Consumption in Idle30 W
  • Power Supply100 to 240 VAC, 50/60 Hz, Max. 6.5 A
  • Max. Power Consumption400 W
  • Approval
  • EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
  • SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
  • ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
,
  • Ports24 × 10/100 Mbps PoE ports, 2 × Gigabit combos
  • Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
  • Working ModeStandard mode (default); Extend mode
  • StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
  • Forwarding ModeStore-and-forward switching
  • High Priority PortsPorts 1 to 8
  • MAC Address Table4 K
  • Switching Capacity8.8 Gbps
  • Packet Forwarding Rate6.547 Mpps
  • Internal Cache2.75 Mbits
  • Ports for Long-Distance TransmissionPorts 17 to 24
,
  • PoE StandardIEEE 802.3af, IEEE 802.3at
  • PoE Power Pin

    End-span: 1/2(-), 3/6(+)

    Mid-span: 4/5(+), 7/8(-)

    8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)

  • PoE PortPorts 1 to 24
  • Max. Port Power30 W
  • PoE Power Budget370 W
,
  • Long RangePorts 17 to 24: up to 300 m; and the speed rate of the port is 10 Mbps.
,
  • EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
  • SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
  • ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Select Model
From $138.95

Original: $397.00

-65%
HIK DS-3E0326P-E(B) 24 Port Fast Ethernet Unmanaged POE Switch—

$397.00

$138.95

Product Information

Shipping & Returns

Description

24 Port Fast Ethernet Unmanaged POE Switch

  • Intelligent PoE Management.  When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
  • Up to 300 m Long Range PoE Transmission.   The distance between IPCs and switch can reach maximum 300 meters.
  • 4/8-Core Adaptive Power Supply with Less Power Loss.  8-core power supply reduces the power loss on cables.
  • 6KV Surge Protection to Improve Reliability in Harsh Environment.  The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
  • Design for Video Transmission.   VIP port ensures important data transmission when network congestion occurs.

Available models:

DS-3E0326P-E(B)



Product Data

  • Network Parameters
  • Ports24 × 10/100 Mbps PoE ports, 2 × Gigabit combos
  • Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
  • Working ModeStandard mode (default); Extend mode
  • StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
  • Forwarding ModeStore-and-forward switching
  • High Priority PortsPorts 1 to 8
  • MAC Address Table4 K
  • Switching Capacity8.8 Gbps
  • Packet Forwarding Rate6.547 Mpps
  • Internal Cache2.75 Mbits
  • Ports for Long-Distance TransmissionPorts 17 to 24
  • PoE Power Supply
  • PoE StandardIEEE 802.3af, IEEE 802.3at
  • PoE Power Pin

    End-span: 1/2(-), 3/6(+)

    Mid-span: 4/5(+), 7/8(-)

    8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)

  • PoE PortPorts 1 to 24
  • Max. Port Power30 W
  • PoE Power Budget370 W
  • Dialing Function
  • Long RangePorts 17 to 24: up to 300 m; and the speed rate of the port is 10 Mbps.
  • General
  • Dimensions (W × H × D)440 mm × 44 mm × 220.8 mm
  • ShellMetal material
  • Gross Weight 3.62 kg (7.98 lb)
  • Net Weight2.75 kg (6.06 lb)
  • Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
  • Operating Humidity5% to 95% (no condensation)
  • Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
  • Storage Humidity5% to 95% (no condensation)
  • Power Consumption in Idle30 W
  • Power Supply100 to 240 VAC, 50/60 Hz, Max. 6.5 A
  • Max. Power Consumption400 W
  • Approval
  • EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
  • SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
  • ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
,
  • Ports24 × 10/100 Mbps PoE ports, 2 × Gigabit combos
  • Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
  • Working ModeStandard mode (default); Extend mode
  • StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
  • Forwarding ModeStore-and-forward switching
  • High Priority PortsPorts 1 to 8
  • MAC Address Table4 K
  • Switching Capacity8.8 Gbps
  • Packet Forwarding Rate6.547 Mpps
  • Internal Cache2.75 Mbits
  • Ports for Long-Distance TransmissionPorts 17 to 24
,
  • PoE StandardIEEE 802.3af, IEEE 802.3at
  • PoE Power Pin

    End-span: 1/2(-), 3/6(+)

    Mid-span: 4/5(+), 7/8(-)

    8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)

  • PoE PortPorts 1 to 24
  • Max. Port Power30 W
  • PoE Power Budget370 W
,
  • Long RangePorts 17 to 24: up to 300 m; and the speed rate of the port is 10 Mbps.
,
  • EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
  • SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
  • ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
