HIK DS-2SK6C425MWG1/LM-L/28(F1F1) DeepinViewX Omni PTZ 4 MP 25X Powered by DarkFighter Network Speed Dome
HIK DS-2SK6C425MWG1/LM-L/28(F1F1) DeepinViewX Omni PTZ 4 MP 25X Powered by DarkFighter Network Speed Dome
DS-2SK6C425MWG1/LM-L/28(F1F1) is a Professional Recorder Network Camera for professional security projects, retail installations, and B2B deployment.
Key Highlights
- Captures two bullet channels and great details at the same time
- High quality imaging with 4 MP resolution for bullet channels
- Excellent low-light performance with Powered by DarkFighter 2.0 technology
- Bullet channel pan adjustable from 0° to 190°, tilt adjustable from 12.5° to 22.5°
- Secures an expansive area with 25 × optical zoom and 16 × digital zoom
- Expansive night view with up to 20 m White light distance and 200 m IR distance
- Supports deep learning functions
- Dedicated large scale AI model for perimeter protection
- Water and dust resistant (IP67) and vandal resistant (IK10) excluding glass window
Specification
Camera
| Image Sensor |
[Panoramic channel] 1/1.8" Progressive Scan CMOS [PTZ channel] 1/2.8" Progressive Scan CMOS |
| Min. Illumination |
[Panoramic channel] Color: 0.0005 Lux @ (F1.0, AGC ON), B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light [PTZ channel] Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed | 1 s to 1/30000 s |
| Slow Shutter | Yes |
| Day & Night |
[Panoramic channel] No [PTZ channel] Auto, Night, Schedule, Day |
| Zoom |
[Panoramic channel] No [PTZ channel] 25× optical, 16× digital |
| Max. Resolution |
[Panoramic channel] 2688 × 1520 [PTZ channel] 2688 × 1520 |
Lens
| Focus | Auto, semi-auto, manual |
| Focal Length |
[Panoramic channel] 4 mm [PTZ channel] 5.3 to 110 mm |
| FOV |
[Panoramic channel] - [PTZ channel] horizontal FOV: 57.7° to 2.9°, vertical FOV: 33.2° to 1.6°, diagonal FOV: 65.2° to 3.3° |
| Aperture |
[Panoramic channel] F1.0 [PTZ channel] F1.6 |
Illuminator
| Supplement Light Range |
[Panoramic channel] White Light: up to 15 m [PTZ channel] White Light: up to 20 m, IR: up to 200 m |
| Smart Supplement Light | Yes |
PTZ
| Movement Range (Pan) |
[Panoramic channel] 0° to 190° [PTZ channel] 0° to 360° |
| Movement Range (Tilt) |
[Panoramic channel] 12.5° to 22.5° [PTZ channel] -10° to 90° |
| Pan Speed |
[Panoramic channel] Configurable from 0.1° to 20°/s, preset speed: 20°/s [PTZ channel] Configurable from 0.1° to 210°/s, preset speed: 280°/s |
| Tilt Speed |
[Panoramic channel] Configurable from 0.1° to 20°/s, preset speed: 20°/s [PTZ channel] Configurable from 0.1° to 150°/s, preset speed: 250°/s |
| Proportional Pan |
[Panoramic channel] No [PTZ channel] Yes |
| Presets | 300 |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans, record time over 10 minutes for each scan |
| Power-off Memory | Yes |
| Park Action | Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan |
| 3D Positioning | Yes |
| PTZ Status Display | Yes |
| Preset Freezing | Yes |
| Scheduled Task | Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output |
Video
| Main Stream |
[Panoramic channel] 50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) [PTZ channel] 50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
[Panoramic channel] 50 Hz: 25 fps (1200 × 536, 960 × 432) 60 Hz: 30 fps (1200 × 536, 960 × 432) [PTZ channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream |
[Panoramic channel] No [PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Video Compression |
Main stream: H.265+ / H.265 / H.264+ / H.264 Sub-stream: H.265 / H.264 / MJPEG Third stream: H.265 / H.264 / MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline profile, Main profile, High profile |
| H.265 Type | Main profile |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
Audio
| Audio Compression | G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC, MP3 |
| Audio Sampling Rate | 8 kHz, 16 kHz, 32 kHz, 48 kHz |
Network
| API | ISAPI, SDK, ISUP |
| Security | Password protection, complicated password, HTTPS encryption, IP address filter, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, host authentication (MAC address), TPM 2.0 (FIPS 140-2 level 2) |
| Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, FTP |
| Simultaneous Live View | Up to 20 channels |
| User/Host | Up to 32 users. 3 user levels: administrator, operator, and user |
| Client | iVMS-4200, HikCentral Pro, Hik-Connect |
| Web Browser |
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+ |
| Wide Dynamic Range (WDR) | 120 dB |
| Day/Night Switch | Day, night, auto, schedule |
| Image Enhancement | HLC, 3D DNR |
| Privacy Mask |
[Panoramic channel] 8 programmable polygon privacy masks [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable |
| Defog | Optical defog |
| Image Stabilization | EIS |
| Regional Exposure | Yes |
| Regional Focus |
[Panoramic channel] No [PTZ channel] Yes |
| Image Settings | Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser |
| Image Parameters Switch | Yes |
| SNR | ≥ 52 dB |
Supplement Detection
| Satellite Positioning | No |
| Gyroscope | Yes |
| Compass | No |
Interface
| Ethernet Interface | 1 RJ45 100M self-adaptive Ethernet port |
| On-board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB |
| Alarm | 7 input(s), 2 output(s) |
| Audio |
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω |
| RS-485 | 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Reset | Yes |
Large Models
| Perimeter Protection |
- Line crossing, intrusion, region entrance, region exiting - Supports alarm triggering by specified target types (human and vehicle) - Supports combined event alarm triggering - Dedicated Large scale AI model for perimeter protection, reduce false alarms by 90% compared to conventional AI cameras |
Event
| Basic Event |
[PTZ channel & panoramic channel] alarm input and output, exception [PTZ channel] motion detection, video tampering alarm |
| Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, loitering detection, people gathering detection, fast moving detection, parking detection |
| Linkage | Upload to FTP/NAS/memory card, white light flashing, send email, notify surveillance center, audible warning, trigger alarm output |
Deep Learning Function
| Intelligent Transportation System |
Traffic Violation Evidence Collection: illegal parking, reverse driving, over lane line detection, continuous lane change, motor vehicle on non-motor vehicle lane, U-turn, slalom driving, illegal lane change, and queue jumping. Traffic Data Collection: Traffic Flow. Road incident detection: (1) Road incident detection for highways and elevated roads: fallen object detection, pedestrian detection, congestion detection, roadblock detection, construction detection, traffic accident detection, fog detection, smoke detection, and fire detection; (2) Road incident detection for urban roads: congestion detection, roadblock detection, construction detection, traffic accident detection, fog detection, smoke detection, and fire detection. Supports general highway incident detection: pothole detection, crack detection, and alligator cracking detection. |
| AcuSeek | This function requires use with AcuSeek NVR/Servers |
| Multi-Target-Type Detection | Supports simultaneous detection and capture of human body, face and vehicle |
General
| General Function | mirror, password protection |
| Power | 36 VDC ± 25%, max. 90 W (Max. 75 W, including max. 18 W for IR and max. 6 W for heater) |
| Operating Condition |
-40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing); For speaker: -30 °C to 55 °C (-22 °F to 131 °F) |
| Wiper | No |
| Demist | Yes |
| Material | ADC12 |
| Dimension | Ø429 mm × 300 mm (Ø16.89" × 11.81") |
| Weight | Approx. 7.9 kg (17.38 lb.) |
| Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
Approval
| EMC |
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7) |
| Safety | CB (IEC 62368-1: 2014 + A11); CE-LVD (EN 62368-1: 2014/A11: 2017) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | IP67 (IEC 60529-2013), TVS 6000 V lightning protection, surge protection and voltage transient protection, IK10 (IEC 62262:2002, excluding glass window) |
$3,500.00
Original: $10,000.00
-65%HIK DS-2SK6C425MWG1/LM-L/28(F1F1) DeepinViewX Omni PTZ 4 MP 25X Powered by DarkFighter Network Speed Dome—
$10,000.00
$3,500.00Product Information
